This machine is suitable for automatic packaging of Tomato Cucumber Carrot ,spinach, lettuce,leeks, cabbage, beansm onions and other vegetables.
I,Main performance and structural characteristics:
1,The touch screen operation is intuitive and easy to understandm,English and Chinese operation interface.
2,The equipment adopts servo control system,the product transmission and packaging sealing is controlled by double servo drive and frequency converter, and good stability.
3,The electric eye automatically recognizes the length of the material to make bags and cut bags,Long and short products can be packed at the same time without adjustment.
4,No film when no material is packed, no empty package will be produced, and packaging materials will be saved.
5,The machine has the function of saving records. When the packaged product is replaced, it can be directly produced by normal swtiching.
6,It can recognize the length of various vegetables in bag,and will not empty the bag when there is no vegetable supply.
7,The machine transmission structure is simple and easy to operate.
8,Separate temperature PID temperature regulator, better to adapt to a variety of packaging materials.
II,Scope of application
This machine is suitable for automatic packaging of Tomato Cucumber Carrot ,spinach, lettuce,leeks, cabbage, beansm onions and other vegetables.
type
KL-T600X
film width
Max.600mm
bag length
Will indentify the length of the vegetables, automatic packaging
bag width
50-280mm
product height Max
Max.120mm
film roll diameter
Max.320mm
packing speed
20-120bag/min
power specifications
220V,50/60HZ,2.8KVA
machine size
L4020*W920*H1450mm
machine weight
950kg
Optional device
1. Automatic date printer
2. The automatic air vent
3. servo motor for preventing
4. Extra big screen
Company Profile
Foshan Newkeli Packaging Equipment was Founded in 2004, the production located in Foshan City, Guangdong Province, specializing in a variety of packaging machinery research, development and production.
Main products include: pillow packaging machine, vertical packaging machines, automatic packaging machines , full automatic feeding machine and related packaging equipment.
"high quality, low price, honesty and best service" is our aim.
Currently our machines have been sold to most countries in the world, like America, Canada, UK, Brazil, Columbia, Russia, Egypt, UAE, Dubai, Japan, Thailand, Taiwan, Hongkong, Vietnam, Maylasia, Turkey, Jordan etc. What our goal is to solute your packing troubles. Our engineer can go every area in the world to support you with a little charge.
