Fresh Fruit packaging or Vegetable Flow Packaging Machine ,bag packaging machine for supermaket ,
+86 13923117139
+8615889953701
Fresh Fresh Fruit And Vegetable Flow Packaging Machine Features:
1. Inverter motor or servo motor control, double Panasonic transducer and PLC controller flexible bag length setting and cutting,saving time and film.
2. Human-machine interface, convenient and quick parameter settings.
3. Self diagnosis failure function, failure displayed clearly.
4. High sensitive optical electric color mark tracking system and digital input cut position, which make the sealing and cutting more accurate.
5. Separated PID control system for temperature, suitable for various packing materials.
6. Stopping the machine in selected position, no sticking on the knife and no waste of them.
7. Simple driving system, reliable working, convenient maintenance.
8. All controlled by program, convenient for function adjusting and upgrading.
Optional device features :
1. Date coder printer
2. Automatic Punching Device
3. Full Stainless Steel (SS304)
4.Touch screen/Digital Display
(Ultra large touch screen)
5. Release the air
6. No empty bag function
7. Automatic feeder
8. Customized sealing patterns and notch
9. Single,Twin, triple,quad jaws for high speed for your choose
10. Gas device for modified atmosphere packaging(Nitrogen Charging Device,Air filling device)
Fresh Fruit And Vegetable Flow Packaging Machine Advantages:
1. All of machines from us obtained CE certificate.
2.We test the packing machine according to your
needs
before delivery to make sure the machine fit the materials
and your products well.
3.We will
make a video for you before delivery to let you check the quality.
4.Our technicians get rich experiences in making packing machine.
5.We have made many packing machines of pinpoint accuracy for domestic
and abroad large enterprises.
Fresh Fruit And Vegetable Flow Packaging Machine
1. Easy to operate
2. High quality and reasonable price
3. CE certification
4. One yeas warranty
5. Reliable performance
Packing material:
Heatsealable laminated film,such as: OPP,PE,PVC,PT/PE,OPP/CPP, other special sealable packing film.Sealing Type:Back-sealed( 3 sides sealed)
1.Standard Pillow Style Bag
2.Pillow Style Bag With Hole Punch / Euro Slot
3.Gusseted Pillow Style Bag
Specification:
|
||||
Model |
KL-400 |
KL-450 |
KL-600 |
KL-680 |
Film Width |
Max.400mm |
Max.450mm |
Max.600mm |
Max.680mm |
Bag Length |
150-400mm |
150-450mm |
160-500mm |
180-600mm |
Bag Width |
50-180mm |
50-180mm |
100-280mm |
100-320mm |
Products High |
Max.65mm |
Max.75mm |
Max.110mm |
Max.110mm |
Film Roll Diameter |
Max.320mm |
Max.320mm |
Max.320mm |
Max.320mm |
Packing Speed |
30-150bag/min |
30-150bag/min |
20-150bag/min |
20-130bag/min |
Power |
220V 50/60Hz 2.8KW |
220V 50/60Hz 2.8kw |
220V 50/60Hz 2.8kw |
220V 50/60Hz 2.8kw |
Machine Size |
4030*770*1420 |
4030*820*1420 |
4030*970*1500 |
4030*1070*1500 |
Machine Weight |
About 550kg |
About 600kg |
About 680kg |
About 720kg |
Fresh friut and vegetable flow packaging machine with tray packaging sample:
