mexico tortilla chips automatic packing machine Features Function ：
This machine can finish measuring, pulling, feeding, forming, date printing, cutting automatically
Adopts the stainless steel 201 for the machine's mainframe, and stainless steel 304 for the parts touching supplies
Fine packaging performance ,low noise ,clear sealing texture and strong sealing performance.
mexico tortilla chips automatic packing machine Specification:
kl-520 Vertical packing machine
|
|
|
Bag length
|
50-300mm(L)
|
|
Bag width
|
50-300 mm (w)
|
|
Max rolling film
|
420 mm
|
|
Material
|
304
|
|
Packing speed
|
10-60bags/min
|
|
Air consumption
|
0.65Mpa
|
|
Gas consumption
|
0.3m3/min
|
|
Voltage
|
220V/50Hz
|
|
Power
|
2.2KW
|
|
Dimension
|
1080mm(L)*1300mm(W)*1400mm(H)
|
|
Machine weight
|
600KG
|
|
10 heads scale(weigher)
|
|
|
|
Max. Cap.(g)
|
10-1000g
|
|
Weighing Accuracy(g)
|
±0.5-2g
|
|
Max. Weighing Speed
|
65PPM
|
|
Hopper Volume
|
1600ml
|
|
Control Panel
|
7 "LCD Touch Screen
|
|
Options
|
Dimple Plate/Timing Hopper/Printer/Rotary Top Cone
|
|
Driving System
|
Step Motor
|
|
Power Requirements
|
220V / 1000W / 50/60HZ / 10A
|
|
Packing Dimension(mm)
|
1620(L)x1100(W)x1100(H)
|
|
Gross WGT
|
420KG
|
| |
|
|
|
|
Z-shape material elevator
|
|
| |
Model
|
kl--350
|
|
Convey speed
|
3750mm/min
|
|
Power
|
750W
|
|
Convey Measure
|
4T/H(Rice)
|
|
Overall size
|
3000(L)×650(W)×3750(H)mm
|
|
Platform for scale(weigher)
|
|
| |
Model
|
-2-2 Platform
|
|
Maximum Loading Weight
|
2T-3T
|
|
Equipment Size
|
2000mm*2000mm*2000mm
|
|
Net Weight
|
350kg
|
|
Finish product conveyor
|
|
| |
Model
|
kl-420
|
|
Convey speed
|
30M/min
|
|
Belt
|
Food grade polypropylene(PP)
|
|
Voltage
|
Single-phase AC220V,50HZ
|
|
Power
|
40W
|
|
Packing size
|
1600mm(L)*520mm(W)*1000mm(H)
|
mexico tortilla chips automatic packing machine ApplicationstThis machine can be used to pack all kind of grain and granule,like coffee,suger,salt,beans,creamer,seasoning,desiccant,washing powder,etc. or big grains, such as pills,tablets,capsule,candies,nuts,peanuts,dry fruits,agricultaral product,etc. or slice,block,bar products, and pruffed foods, such as oil fried food,potato slices,shrimp slices,crispyrice and so on.
