Coconut powder packing machine Usage:
Suitable for packing high accuracy and easy fragile material,such as: puffed food,crispy rice,Potato Chips,candy,pistachio,apple slices,dumpling,chocolate,pet food,small wares,biscuit,roasted,seeds,
cooked food, rice, salt, candies, snack, sugar, pulses, grain, beans, washing powder, roasted peanuts,deep-frozen,amylum,sauce,tea,milk powder,milk tea,chili powder, etc.
Coconut powder packing machine
Main features:
1.This machine is equipped with safely protection, comply with firm's safety Management requires.
2.Use intelligent temperature controlling machines to have accurate temperature Control ensure the artistic and neat seal.
3.Use PLC Servo System and pneumatic control system and super touch screen to form the drive control center;
4.This machine completes the whole packing procedure of measuring, loading materials, bagging, date printing, charging (exhausting) and products transporting automatically as well as counting.
5.Touch screen can store the technical parameters of various kinds of products, no need to reset while products changing.
6.Have error indicating system, helping to handle the trouble immediately.
7.Make block bags and hanging bags according to customers' different requires.
8.Both stainless steel machines and carbon steel machines.
9.Single-belt transportation, placidly and quickly, small friction, little waste.
Coconut powder packing machine parameters:
Type
|
kl-420
|
Packing range
|
10-1kg
|
Making bag size
|
L: 60-300mm,W80-200mm
|
Width of roll film
|
Max.420mm
|
Packing speed
|
1-50 bags/min
|
Electric source and power
|
1Ph. AC220V, 50/60Hz, 5kw
|
Compressed air costs
|
6-8kg/m2, 0.15m3/min
|
Machine weight
|
500KG
|
Machine dimension
|
L1650×W1300×H1700mm
|
Type
|
kl-520
|
Packing range
|
1-2.5kg
|
Making bag size
|
L: 80-400mm,W150-250mm
|
Width of roll film
|
Max.520mm
|
Packing speed
|
5-50 bags/min
|
Electric source and power
|
1Ph. AC220V, 50/60Hz, 5kw
|
Compressed air costs
|
6-8kg/m2, 0.25m3/min
|
Machine weight
|
550KG
|
Machine dimension
|
L1500×W1140×H1540mm
|
Type
|
kl-720
|
Packing range
|
2-4kg
|
Making bag size
|
L: 80-450mm,W200-350mm
|
Width of roll film
|
Max.720mm
|
Packing speed
|
5-40 bags/min
|
Electric source and power
|
AC220V, 50/60Hz, 4.75kw
|
Compressed air costs
|
6-8kg/m2, 0.3m3/min
|
Machine weight
|
700KG
|
Machine dimension
|
L1800×W1250×H1780mm
|
cocoa powder packing machinepackaging sample:
