snack packaging machine automatic weighing and filling machine with multi-head weighing Application: Suitable for packing fragile bulk material with irregular shapes and requiring high measuring accuracy, such as :puffed food, shrimp strip, potato chips, banana chips, apple flakes, crispy rice,...
Snack packaging machine
automatic weighing and filling machine with multi-head weighing
Application:
Suitable for packing fragile bulk material with irregular shapes and requiring high measuring accuracy, such as :puffed food, shrimp strip, potato chips, banana chips, apple flakes, crispy rice, biscuit, rusk bread, Mexico Tortilla, corn flake ~
1.KL-420MAIN MACHINE(Adjust accordingpacking size)
2.Ten heads combined scale
3.Z type material conveyor (includingvibrate hopper)
4.Supporting platform
5.Finished product conveyor
Packaging bag sample:
Feature :
The system can finish automatically all the process, eg. Feeding, measuring, filling and bag making, printing date, product output.
The machine structure is compact, rational, stable performance, easy operation and maintenance.
The complete set of the machine is featured with fair price, stable performance.
The machine adopts independent mixing system ,it is able to mix uniformly the material .
Specificaton of Packing Machine( chose according your packaging bag size)
|
Item No. |
KL-720 |
KL-520 |
KL-420 |
KL-350 |
|
Bag length |
100-500mm |
80-350mm |
50-300mm |
100-230mm |
|
Bag width |
100-350mm |
80-250mm |
60-200mm |
75-165mm |
|
Film width |
Max.720mm |
Max.520mm |
Max.420mm |
Max.350mm |
|
Capacity |
Max.5000ml |
Max.2000ml |
150-1400ml |
150-700ml |
|
Film Thickness |
0.04-0.08m m |
|||
|
Film applied |
CPP/OPP, OPP, laminated film etc. |
|||
|
Packing speed |
Max 10-20bag/min |
Max 10-50bag/min |
Max 10-55bag/min |
Max 10-60bag/min |
|
Outside size of packing machine |
(L)1680*(W)1350*(H)2800(mm) |
(L)1430*(W)1200*(H)2700(mm) |
(L)1400*(W)970*(H)2600(mm) |
(L)1400*(W)970*(H)2600(mm) |
|
Air consumption |
350L/min 0.6 *105Pa |
350L/min 0.6 *105Pa |
350L/min 0.6 *105Pa |
350L/min 0.6 *105Pa |
FAQ
Normally we have some questions to customers,
1. What is you want to pack?
2. How many grams to pack?
3. What size of bag?
4. What is voltage and Hertz in your local?
Optional part:
1.nitrogen gas filling device
2.date printer
3.weigh checker
4.end sealing size
5.euro hole device
