Up Paper Rotary Horizontal Flow packing machine Features:
· Dual frequency conversion control, bag length can be set and
cutting in one step ,saving time and films.
· Interface features are easy and quick setting and operating.
· Self diagnosis failure function, clear failure display.
· High sensitivity photoelectric eye color tracing, numerical input of
cutting sealing position for extra accuracy.
· Temperature independent PID control, more suitable for packing
different materials.
· Positioned stop function, without sticking knife or wasting film.
· Simple driving system, reliable working, convenient maintenance.
· All control is realized through software, easy for function adjusting
and technical upgrade.
Application: Food: Biscuit Bread, pies, cake, chocolate bar, noodle,
candy
Vegetables and Fruits: apples, bananas, lettuce, potatoes, tomatoes,
peppers, cucumbers, etc.
Hardware: hinge, stainless steel pipe, bearings , screw, nuts and
washer, etc
Hotel Supplies: soap, disposable comb, tooth paste and brush in one
set.
Stationary: pencil, eraser, notebook, paper card, adhesive tape, etc.
Electric Products: battery, cable, earphone, user manual and
accessories in one set.
Medical: face mask, glove, gauze, capsule, disposable syringe, etc.
Daily use: plastic knife, fork, plate, sponge, scourer, wipes, several
straws in a bag, gift, cups, bottles, napkin, baby diaper, etc.
Specification: | ||||||
Model | Kl-250 | KL-350 | KL-400 | KL-450 | KL-600 | KL-680 |
Film Width | Max.250 | Max.350mm | Max.400mm | Max.450mm | Max.600mm | Max.680mm |
Bag Length | 65-195 or120-280 | 65-190 or 120-330mm |
150-400mm | 150-450mm | 160-500mm | 180-600mm |
Bag Width | 30-110mm | 50-160mm | 50-180mm | 50-180mm | 100-280mm | 100-320mm |
Products High | Max.60mm | Max.60mm | Max.65mm | Max.75mm | Max.110mm | Max.110mm |
Film Roll Diameter |
Max.320mm | Max.320mm | Max.320mm | Max.320mm | Max.320mm | Max.320mm |
Packing Speed | 40-230bag/mins | 40-180bag/min | 30-150bag/min | 30-150bag/min | 20-150bag/min | 20-130bag/min |
Power | 220v 50/ 60hz 2.6kw |
220V 50/60Hz 2.6kw |
220V 50/60Hz 2.8KW |
220V 50/60Hz 2.8kw |
220V 50/60Hz 2.8kw |
220V 50/60Hz 2.8kw |
Machine Size | 3770*670*1450 | 4030*770*1420 | 4030*770*1420 | 4030*820*1420 | 4030*970*1500 | 4030*1070*1500 |
Machine Weight | About 450kg | About 500kg | About 550kg | About 600kg | About 680kg | About 720kg |
