servo horizontal packing machine

We're known as one of the most professional servo motor horizontal packing machine manufacturers and suppliers in China for our quality products and good service. Please rest assured to buy bulk servo motor horizontal packing machine at low price from our factory.



CONTACT US

01. Servo control system, flexible bag length cutting, operator needn’t to adjust the unloading working, saving time and saving films.

02. man-machine operation, convenient parameter setting.

03. Fault self-diagnosis function, clear failure display.

04. Sensitivity photoelectric eye tracking, digital input cut position which makes the cutting position more accurate.

5. Temperature independent PID control, better suitable for various packaging materials.

6. Located the stop function, not stick to the knife, not waste the film.

7. The transmission system is simple, working is more reliable, and the maintenance is more convenient.

8. All controls are implemented by software, convenient for functional adjustment and technical upgrade, and never lag behind.

9. Automatic optical scanning material length, automatic fix bag length!

(二)Scope of applicant

Food: cake, bread, biscuits, cookies, meat muffin, flaky pastry, moon cake, several sausage in a bag, noodles, beef jerky, egg roll, etc
Vegetables and Fruits: apples, bananas, lettuce, potatoes, tomatoes, peppers, cucumbers,
Hardwares: hinge, stainless steel pipe, bearings , screw, nuts and washer, etc
Hotel Supplies: soap, disposable comb, tooth paste and brush in one set.
Stationary: pencil, eraser, notebook, paper card, adhensive tape
Electric Products: battery, usb cable, earphone, user manual and accessories in one set.
Medical: face mask, glove, gauze, capsule, disposable syringe.
Daily use: plastic knife, fork, plate, sponge, scourer, wipes, several straws in a bag, cups, bottles, napkin, baby diaper, etc.

Technical Specification (If you can tell us your bag size we will match suitable model to you)

Product Name

Pita Bread  Packing Machine

Model

KL-250X

KL-350X

KL-450X

KL-600X

Film Roll Width

Max 250mm

Max 350mm

Max 450mm

Max 600mm

Packing Speed

40-230bags/min

40-230bags/min

30-150 bags/min

30-150 bags/min

Bag Width

30-110mm

50-160mm

60-210mm

60-280mm

Bag Length

90-220mm or 150-330mm

90-220mm or 150-330mm

120-450mm

130-450mm

Product Height

Max 40-70mm

Max 45-70mm

Max 100mm

Max 100mm

Power

220V 50HZ/60HZ 2.4KVA

220V 50HZ/60HZ 2.4KVA

220V 50HZ/60HZ 2.6KVA

220V 50HZ/60HZ 2.6KVA

Machine Size

L3770*W670*H1450

L3770*W745*H1450

L3990*W900*H1468

L3990*W1000*H1468

Option Device

Nitrogen filling device/  Linking Bags device/ Punching device/Date Printer



 Customiezd large type item film width:



Model

kl-750X

kl-800X

kl-900X

Film Width

Max.100-750mm

Max.100-800mm

Max.100-900mm

Bag Length

120-420/150-500/180-600mm

120-420/150-500/180-600mm

120-420/150-500/180-600mm

Bag Width

50-330mm

50-380mm

40-430mm

Product High

Max.80/100/150

Max.80/100/150

Max.80/100/150

Film Rill Diameter

Max.320mm

Max.320mm

Max.320mm

Packing Rate

20-120bag/min

20-120bag/min

20-120bag/min

Powder

220V/50/60hz
